ARAMICORE® Aramid Honeycomb

aramid honeycomb core in sandwich panels

ARAMICORE® aramid honeycomb exhibits excellent thermal and moisture stability, improved shear strength and modulus, stringent smoke, toxicity and high hot/wet characteristics.

ARAMICORE® aramid honeycomb is aramid paper reinforced honeycomb which is impregnated with phenolic resin. It exhibits excellent thermal and moisture stability, improved shear strength and modulus, stringent smoke, toxicity and high hot/wet characteristics etc. VICWA® aramid honeycomb is an ideal structural material for application in aerospace; aircraft and special vehicles.

ARAMICORE® Aramid Honeycomb -1--high performance fiber

ARAMICORE® Aramid Honeycomb -2--high performance fiber

Features:

Excellent thermal and moisture
Light-weight and high strength
Flame retardant and fireproofing
Anti-fatigue

Main Applications:

Aerospace
Train, vessel
Antenna cover
Celling, side walls, floor, partition in aircraft
